Medical Compressed Gas Connectors
Incorrect connections
correct connections
step 3
Disconnect
• Once pressure is relieved, pull back on sleeve and remove connector.
Figure 17. Connector tight to valve.
Figure 18. Sleeve is forward.
Figure 19. Note excess threads.
Figure 20. Connector loose and sleeve not forward.
MedIcal and IndustrIal cga 540 operatIon
