Medical Compressed Gas Connectors
FasTest, Inc. 1646 Terrace Drive Roseville, MN 55113 Support: (800) 444-2373 Fax: (651) 645-7390 www.fastestinc.com
3
step 2
Safety features:
• If the handle is accidentally disconnected under pressure, the sealing piston
will travel with the valve to retain a seal. The piston will retract and return to
its original position once the pressure has dropped below 250 psig.
Figure 4. MediMate CGA 870, CGA 950
MediMate cga 870 and cga 950 operatIon
step 1
At the start of each shift:
• Check all connectors for main seal condition.
• Check for smooth operation of the handle before the first fill.
• Check seal-face/piston movement.
Sealing
Piston
Body
Main
Seal
Index
Pins
Handle
Incoming Line
Termination
Figure 6. The piston retains position against valve during
accidental disconnection.
