General specifications – ERICO ISODC Isolated Downconductor System User Manual
Page 17
17
www.erico.com
Isolated Downconductor
ISODC (#701130)
Description
XLPE/PE Isolated Cable
Equivalent separation distance
1000 mm of air
Material
Multi-strand aluminum (19 x 1.87 mm dia.). Total cross sectional area 50 mm
2
Color
Black
Outer diameter
27 mm
Minimum bending radius
450 mm
Weight
0.58 kg/m
Installation temperature
> 0 deg C
Operating temperature
-40 deg C to 70 deg C
Termination Adapters
Stainless steel 304.
Lower adapter provides 8 mm diameter, 50 mm stud
Standards
IEC 62305-3
EN 50164-2
UL
®
96A
Air Terminal
AAR1015 (#711070) 1.0 m or AAR0515 (#711020) 0.5 m
Description
Aluminum air terminal, safety tipped
Dimension
16 mm thread, 0.5 or 1.0 m length
Standards
IEC 62305-3, EN 50164-2, UL 96A
Isolated Mast
ISOFRP3M (#701140)
Description
Fiberglass-reinforced thermoset polyester tube (UV stable)
Color
Grey
Diameter
50 mm
Weight
4.2 kg
System
Worst case total system weight
< 16 kg
(Based on 3 m Isolated Mast, air terminal, 10 m of Isolated Downconductor
and 2 x ALOF1GS mounting brackets).
Wind loading
ISOFRP mast withstand speed > 195 km/h. Wind loading on support mast under such
conditions 120 kg
12. GENERAL SPECIFICATIONS
