ERICO CADWELD Electrical Connections User Manual
Page 3
3
www.erico.com
The CADWELD
®
Process ............................ 4
The CADWELD Connection ....................... 5
It’s Easy to Make CADWELD
Connections ............................................... 6
CADWELD Quality Standards ................... 8
Specifications for CADWELD
Connections ............................................... 8
CADWELD Mold Inspection ...................... 9
Inspection of CADWELD Connections
General Indicators .............................. 10
Size ...................................................... 10
Color .................................................... 12
Surface Finish ...................................... 12
Porosity ............................................... 12
Visual Inspection ................................ 13
Photographic Guides ......................... 14
Field Situation Guide ......................... 18
CADWELD
®
ONE SHOT Connections
General Indicators .................................. 22
Field Situation Guide for CADWELD
ONE SHOT Applications .......................... 23
The CADWELD
®
Process
Contents
