Inspection of cadweld, Connections – ERICO CADWELD Electrical Connections User Manual
Page 14
14
www.erico.com
Good.
A solid weld with only minor surface imperfections.
Acceptable.
Fill is lower than normal, but still sufficient.
Acceptable.
A worn or incorrect mold was used, allowing
leakage around conductor. The fill in this connection
is sufficient to allow it as acceptable. Attention to
mold is required prior to making next connection.
Inspection of
CADWELD
®
Connections
Photographic Guides
