Gold Maestro Installation Guide Technical Specifications
MAN-GOLD-MAESTRO-IG (Ver. 1.301)
www.elmomc.com
30
4.4. Power Supply
Feature Details
Auxiliary power supply DC source only
Auxiliary supply input voltage 13 V to 96 V or
20 V to 196 V depending on the model
Auxiliary supply input power 4.5 W
4.5. Communications
Specification Details
Ethernet 100 base-T
Baud Rate: 10/100 Mbit/sec, automatically detected
CAT5e Cable
UDP, Telnet, TCP
USB One port, USB 2.0, 12 Mbps
Used only for setup and determining IP address.
EtherCAT 100 base-T
Baud Rate: 100 Mbit/sec
CAT5e Cable
CoE, EoE, FoE
CAN CAN bus Signals:
CAN_H, CAN_L, CAN_GND
Maximum Baud Rate of 1 Mbits/sec.
CAN Profile:
DS 301
Device Profile (drive and motion control):
CAN device profiles, e.g., DS301, DS505, DS402, DS401
(for I/O)
