MAIN MENU
PROCESS VARS
DISPLAY STATUS
DEVICE STATUS
DISPLAY SETUP
DEVICE SETUP
DISPLAY TEST
PROCESS VARS
USER TEXT XXXXXX
HIGH ALARM Y/N
LOW ALARM Y/N
AUX ALARM Y/N
ANALOG INPUT X.XX MA
ANALOG OUTPUT X.XX MA
URV X.XX
LRV X.XX
FAULT Y/N
DISPLAY STATUS
GENERAL INFO
FAULT/STATUS
HISTORY
DISPLAY INFO
RS485
DEBUG MENU
DISPLAY TEST
SELF TEST
RESPONSE TEST
LOOP TEST
D/A TRIM
FAULT/STATUS
OP MODE XXXXX
FAULT Y/N
STATUS Y/N
GENERAL INFO
MANUFACTURER
MODEL
UD-10
TAG XXXXX
DESCRIPTOR XXXXX
DATE DD/MMM/YYYY
MESSAGE XXXXX
FINAL ASSY NUM XXXXX
DEVICE ID XXXXX
HISTORY
DISPLAY HISTORY
EVENT LOG
DISPLAY INFO
RTC
SERIAL NUMBER
XXXXX
I/O BOARD ID XXX
MFG DATE DD/MM/YYYY
F/W REV XXXXX
UNIVERSAL REV XXXXX
FIELD DEV REV XXXXX
RUNNING HOURS XXXXX
TEMPERATURE XX.XX C
HEATER CTRL AUTO/ON/OFF
BACKLIGHT CTRL AUTO/ON/OFF
INPUT VOLTAGE XX.XX
RS485
BAUD RATE XXXXX
PARITY XXXXX
POLL ADDRESS XXXXX
STATUS
ANY FAULT ON/OFF
CAL ACTIVE ON/OFF
WARM UP ON/OFF
LOW RELAY ACTIVE ON/OFF
HI RELAY ACTIVE ON/OFF
AUX RELAY ACTIVE ON/OFF
CURRENT FIXED ON/OFF
MB WRITE PROTECT ON/OFF
HART SELF TEST ON/OFF
LON ATTACHED ON/OFF
RESPONSE TEST ON/OFF
MANUAL SELF TEST ON/OFF
INPUT HART ON/OFF
DISPLAY HISTORY
RUNNING HOURS XXXX
MAX TEMP XX.XX C
MAX TEMP TIME XX:XX:XX
MIN TEMP ` XX.XX C
MIN TEMP TIME XX:XX:XX
RESET MAX MIN
MAX RESET TEMP
XX.XX C
MAX RESET TIME XX:XX:XX
MIN RESET TEMP XX.XX C
MIN RESET TIME XX:XX:XX
EVENT LOG
EVENT XXXXX
DATE DD/MMM/YYYY
TIME HH:MM:SS
RTC
DISPLAYED Y/N
SECONDS XX
MINUTES XX
HOURS XX
DAY XX
MONTH XX
YEAR XX
RTC
DISPLAYED Y/N
SECONDS XX
MINUTES XX
HOURS XX
DAY XX
MONTH XX
YEAR XX
MODE SELECT
HART DEVICE
PIR9400
C706X
505
NTMOS
CGS
GENERIC DEVICE
RS485
BAUD RATE
PARITY
POLL ADDRESS
XXXX
BAUD RATE
1200
2400
4800
9600
19.2K
PARITY
NONE
EVEN
ODD
D/A TRIM
ZERO TRIM
GAIN TRIM
SET 4-20 MA
3.5 MA
4 MA
6 MA
8 MA
10 MA
12 MA
14 MA
16 MA
18 MA
20 MA
LOOP TEST
SET 4-20 MA
6901 WEST 110 TH STREET
MINNEAPOLIS, MN 55438
USA
FAULTS
HIGH FAULT ON/OFF
LOW FAULT ON/OFF
DEVICE STATUS
FAULT/ STATUS
HIGH FAULT LEVEL
XX.XX
HIGH FAULT ENABLED/DISBALED
LOW FAULT LEVEL XX.XX
LOW FAULT ENABLED/DISBALED
FAULT/ STATUS
FAULTS Y/N
DEVICE SETUP
USER TEXT XXXX
SELECT UNIT
USER UNIT
%
URV XXXX
LRV XXXX
HIGH FAULT LEVEL XX.XX
HIGH FAULT
LOW FAULT LEVEL
XX.XX
LOW FAULT
SELECT UNITS
%
PPM
%LFL
PPB
USER SELECT
HIGH FAULT
DISABLED
ENABLED
LOW FAULT
DISABLED
ENABLED
UNITS CAN BE EDITED
WHEN “USER SELECT”
IS SELECTED
HART OPTION
TAG XXXXX
DESCRIPTOR XXXXX
DATE DD/MMM/YYYY
MESSAGE XXXXX
FINAL ASSY NUM XXXXX
DISPLAY SETUP
ALARM SETTING
MODE SELECT
HART OPTION
RTC
RS485
INPUT LOOP CAL
CONTRAST CONTRL
OUTPUT MODE
BACKLIGHT CTRL
WRITE PROTECT
OP FEEDBACK FLT
OUTPUT MODE
STANDARD
REPLICATE
WRITE PROTECT
CHANGE STATE
CHANGE PASSWORD
WRITE PROTECT
XXXX
ALARM SETTING
RST LATCH ALARMS
HGH ALARM LEVEL
XX.XX
HGH ALARM LATCH Y/N
HGH ALARM NE/ND
LOW ALARM LEVEL
XX.XX
LOW ALARM LATCH Y/N
LOW ALARM NE/ND
AUX ALARM LEVEL
XX.XX
AUX ALARM LATCH Y/N
AUX ALARM NE/ND
BACKLIGHT CTRL
OFF
ON
AUTOMATIC
20-Feb-13 GENERIC 4.21
Detector Electronics
HGH ALARM NE/NDE
NE-NORMALY ENERGIZED
NDE-NORMALY DEENERGIZED
LOW ALARM NE/NDE
NE-NORMALY ENERGIZED
NDE-NORMALY DEENERGIZED
AUX ALARM NE/NDE
NE-NORMALY ENERGIZED
NDE-NORMALY DEENERGIZED
DEBUG MENU
HART ERRORS XXXXX
MODBUS ERRORS XXXXX
OUTPUT READBACK XX.XX MA
ANALOG INPUT XX.XX MA
OP FEEDBACK FLT
OFF
ON
FAULT
LOW CAL LINE ON/OFF
EE FAULT ON/OFF
ADC FAULT ON/OFF
24V FAULT ON/OFF
FLASH FAULT ON/OFF
RAM FAULT ON/OFF
WDT FAULT ON/OFF
12V FAULT ON/OFF
5V FAULT ON/OFF
1.25V FAULT ON/OFF
O/P LOOP FAULT ON/OFF
INPUT LOOP FAULT ON/OFF
0V FAULT ON/OFF
ADC REF FAULT ON/OFF
