Det-Tronics UD10 FlexVu Explosion-Proof Universal Display Unit User Manual
Page 55
4.2
K-3
95-8661
NOTE 1
REMOVE UD10 ELECTRONIC MODULE FOR ACCESS
TO NTMOS CONNECTOR BOARD (NO TOOLS REQUIRED).
NOTE 2
GREY AND ORANGE WIRES FOR FACTORY USE ONLY.
NOTE 3
HOUSINGS MUST BE ELECTRICALLY CONNECTED TO
EARTH GROUND.
UD10
DISPLAY UNIT
B2493
J2
P1
COM 1 (GR
A
Y)
COM 2 (OR
ANGE)
C
AL (YELL
O
W)
R
TN (BLA
CK)
4/20 (WHITE)
24V (RED)
SHIELD
CA
L
RT
N
4/20
24V
CONNECT TO UD10 MODULE’S J3 WITH
FACTORY INSTALLED CABLE
NTMOS CONNECTOR BOARD
NTMOS
H2S DETECTOR
RED
BLA
CK
WHITE
YELL
O
W
GREY
OR
ANGE
nTMoS Detector Wired Directly to UD10 via the nTMoS Connector board
(nTMoS Connector board is
Required for HART Communication)
UD10 with nTMoS Connector board Wired to nTMoS Detector with STb Termination box
(nTMoS Connector board is
Required for HART Communication)
NOTE 1
REMOVE UD10 ELECTRONIC MODULE FOR ACCESS
TO NTMOS CONNECTOR BOARD (NO TOOLS REQUIRED).
NOTE 2
GREY AND ORANGE WIRES FOR FACTORY USE ONLY.
NOTE 3
HOUSINGS MUST BE ELECTRICALLY CONNECTED TO
EARTH GROUND.
UD10
DISPLAY UNIT
B2494
J2
P1
COM 1 (GR
A
Y)
COM 2 (OR
ANGE)
C
AL (YELL
O
W)
R
TN (BLA
CK)
4/20 (WHITE)
24V (RED)
SHIELD
CA
L
RT
N
4/20
24V
STB TERMINATION BOX
NTMOS
H2S DETECTOR
RED
BLA
CK
WHITE
YELL
O
W
GREY
OR
ANGE
CONNECT TO UD10 MODULE’S J3 WITH
FACTORY INSTALLED CABLE
NTMOS CONNECTOR BOARD
