Main Menu
1) Process Variables
2) Display Status Menu
3) Device Status Menu
4) Display Setup
5) Device Setup
6) Device Cal
7) Display Test Menu
Process Variables
1) Gas Name xxxxx
2) Gas Value xxxx.x
3) High Alarm T/F
4) Low Alarm T/F
5) AUX Alarm T/F
6) Analog Output xxxxx
7) Upper Range Value xxxxx
8) Lower Range Value xxxxx
9) Fault T/F
10) SV Value xxxxx
11) TV Value xxxxx
12) QV Value xxxxx
Display Status Menu
1) Display General Info
2) Display Fault/Status Info
3) Display History
4) Display Info
Display Fault/Status Info
1) Operating Mode xxxxx
2) Display Status 1 xxxxx
3) Display Status 2 xxxxx
4) Display Fault 1 xxxxx
5) Display Fault 2
xxxxx
Display RTC
1) Seconds xxxxx
2) Minutes xxxxx
3) Hours xxxxx
4) Day xxxxx
5) Month xxxxx
6) Year xxxxx
Display General Info
1) Manufacturer
2) Tag
xxxxx
3) Descriptor xxxxx
4) Message xxxxx
5) Final Asmbly Num xxxxx
6) Dev ID xxxxx
7) Write Protect xxxxx
8) Model xxxxx
Display History
1) History
2) Event Log
History
1) Running Hrs xxxx
2) Max Temp xx.xx C
3) Max Temp Time
4) Min Temp
xx.xx C
5) Min Temp Time
Display Info
1) Display RTC
2) Serial Number
xxxxx
3) Hardware Rev xxxxx
4) Firmware Revision xxxxx
5) Universal Rev xxxxx
6) Fld Dev Rev xxxxx
7) Software Rev xxxxx
8) DD Build Version
DD/MM/YY HR:MM:SS
xx / xx / xx
xx:xx:xx
Device Status Menu
1) Device Info
2) Device Fault/Status
3) Device Info 2
4) Sensor Info
5) Device History Info
Display Setup
1) Write Protect
2) Alarm Setting
3) Display HART Option
4) Display RTC
Device Setup
1) Device HART Option
Display Test Menu
1) Self Test
2) Response Test
3) Reset
4) Loop Test
5) D/A Trim
Device History Info
1) Calibration Log
Device Info
1) Manufacturer xxxxx
2) Tag xxxxx
3) Descriptor xxxxx
4) Message xxxxx
5) Final Asmbly Num xxxxx
6) Dev ID xxxxx
7) Write Protect xxxxx
8) Model xxxxx
Device Fault/Status
1) Operating Mode xxxxx
2) Calibration State xxxxx
3) Device Status 1 xxxxx
4) Device Status 2
xxxxx
5) Device Fault 1 xxxxx
6) Device Fault 2 xxxxx
7) Device Fault 3 xxxxx
8) Device Fault 4 xxxxx
9) Extended Fault/Status
Device Info 2
1) Serial Number xxxxx
2) Hardware Revision xxxxx
3) Firmware Revision xxxxx
4) Universal Rev xxxxx
5) Fld Dev Rev xxxxx
6) Software Rev xxxxx
Sensor Info
1) Sensitivity xxxxx
2) Gas Name xxxxx
3) Revision xxxxx
4) PV USL xxxxx
5) PV LSL xxxxx
6) Hours xxxxx
7) Serial Number xxxxx
8) Hardware Revision xxxxx
9) Firmware Revision xxxxx
Cal Point Zero xxxxx
Cal Point Span xxxxx
Device Fault 1
Loop Fault ON/OFF
Supply Voltage Fault ON/OFF
Calibration Fault ON/OFF
Memory Fault ON/OFF
ADC Fault ON/OFF
Internal Voltage Fault ON/OFF
Zero Drift ON/OFF
Temperature Sensor Fault ON/OFF
Device Fault 2
Wrong Sensor Type ON/OFF
Lamp Fault ON/OFF
Alignment Fault ON/OFF
Blocked Optic Fault ON/OFF
Cal Line Active ON/OFF
Sensor Fault ON/OFF
Noise Fault ON/OFF
Align ADC Fault ON/OFF
Device Fault 3
Align Fault ON/OFF
Align Warning ON/OFF
DAC Fault ON/OFF
High Fault ON/OFF
Low Fault ON/OFF
Device Warm Up ON/OFF
Ref Channel Fault ON/OFF
Act Channel Fault
ON/OFF
Device Fault 4
Incompatible Version ON/OFF
Detection Disable Fault ON/OFF
Oi Fault ON/OFF
Diminished Detect Fault ON/OFF
Communication Fault ON/OFF
Reserved ON/OFF
Reserved ON/OFF
General Fault ON/OFF
Device Status 1
Calibration Active ON/OFF
Warm Up ON/OFF
Low Alarm ON/OFF
Aux Alarm ON/OFF
High Alarm ON/OFF
Self Test ON/OFF
Configuration Change ON/OFF
Alignment Mode ON/OFF
Device Status 2
Write Protect ON/OFF
Response Test ON/OFF
4-20 Fixed ON/OFF
Sensor Removed ON/OFF
Sensor End Of Life ON/OFF
Loop Test Active ON/OFF
TDSA Alarm
ON/OFF
Quick Alarm ON/OFF
Calibration Log
--------------------------------------------------
Calibration Log
CalCode: xx Timestamp: xxxxxxxxx
-----------------------------------------------
First
Previous
Next
End
Display HART Option
1) Tag xxxxx
2) Descriptor xxxxx
3) Message xxxxx
4) Date xxxxx
5) Final asmbly num xxxxx
Display RTC
1) Seconds xxxxx
2) Minutes xxxxx
3) Hours xxxxx
4) Day xxxxx
5) Month xxxxx
6) Year xxxxx
Device HART Option
1) Tag xxxxx
2) Descriptor xxxxx
3) Message xxxxx
4) Final asmbly num xxxxx
Loop Test
1) 4 mA
2) 20 mA
3) Other
4) End
Event Log
1) Event Log
Event Log
___________________________
XXXX On dd/mm/yy-hh:mm:ss
--------------------------------------------
First
Previous
Next
End
Display Status 2
Any Fault ON/OFF
CAL Active ON/OFF
Warm up Mode
ON/OFF
Low Relay Active ON/OFF
Hi Relay Active ON/OFF
Aux Relay Active ON/OFF
Current Fixed ON/OFF
MB Write Protect ON/OFF
Display Fault 1
12V Fault ON/OFF
5V Fault ON/OFF
3V Fault ON/OFF
Reserved ON/OFF
Output Loop FLT ON/OFF
Input Loop FLT ON/OFF
Reserved ON/OFF
Reserved ON/OFF
Display Fault 2
Reserved ON/OFF
Reserved ON/OFF
FRAM Fault ON/OFF
ADC Ref Voltage Fault ON/OFF
24V Fault ON/OFF
Flash Fault ON/OFF
RAM Fault ON/OFF
WDT Fault ON/OFF
DET-TRONICS
Display Status 1
Cal Line Active ON/OFF
Cal SW Active ON/OFF
HART Test ON/OFF
LON Attached ON/OFF
Response Test ON/OFF
Manual Self Test ON/OFF
Input HART ON/OFF
Reserved ON/OFF
Alarm Setting
Rst Latch Alarms
High Alarm Level
xx.xx
High Alarm Latch Y/N
High Alarm NE/NDE
Low Alarm Level
xx.xx
Low Alarm Latch Y/N
Low Alarm NE/NDE
Auxilary Alarm Level xx.xx
Aux Alarm Latch
Y/N
Aux Alarm NE/NDE
Device Cal
1) Sensor Calibration
Calibration
1) Execute
2) Abort
Extended Fault/Status
Extended Byte 0 xxxxx
Extended Byte 1 xxxxx
Extended Byte 2 xxxxx
Extended Byte 3 xxxxx
Extended Byte 4 xxxxx
Extended Byte 5 xxxxx
Extended Byte 6 xxxxx
Extended Byte 7 xxxxx
Write Protect
1) Change Mode
2) Write Protect
Y/N
20-Feb-13
HART
Handheld
4.21
Detector Electronics
