7. Random Access Adjustment Mode
7.6.3 Picture in Picture source
Which source displayed in PiP
1. Push the cursor key ↑ or ↓ to highlight Source.
PIP
STATUS [ON]
SOURCE 01
POSITION [Top-Left]
QUICK SELECT [OFF]
Select with ↑ or ↓
then
to return
Menu 7-55
2. Press ENTER to select.
3. Enter the source number with the remote control. Start always with 0.
7.6.4 Position of Picture in Picture window
What can be done?
The PiP window can be placed in on of the four corners of the main window.
How to position?
1. Push the cursor key ↑ or ↓ to highlight Position.
PIP
STATUS [ON]
SOURCE 01
POSITION [Top-Left]
QUICK SELECT [OFF]
Select with ↑ or ↓
then
to return
Menu 7-56
2. Press ENTER to toggle between Top-Left, Top-Right, Bottom-Left or Bottom-Right.
7.6.5 Set up of the Quick Selection
What is possible?
When the quick selection is active, the source inside the PiP window can be switched to another source by entering on the RCU or
local keypad first 0 followed immediately by the source number. E.g. for source 2 in the PiP window, enter 02 on the RCU.
How to set
1. Push the cursor key ↑ or ↓ to highlight Quick Select.
PIP
STATUS [ON]
SOURCE 01
POSITION [Top-Left]
QUICK SELECT [OFF]
Select with ↑ or ↓
then
to return
Menu 7-57
2. Press ENTER to toggle between [OFF] and [<0>].
OFF : no quick selection allowed.
<0> : quick selection allowed by using 0 before the source number.
