8. Installation Mode
To view or the change the input configuration.
1. Push the cursor key ↑ or ↓ to highlight Input Slots.
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
SOURCE SWITCHING
NO SIGNAL
CONTRAST ENHANCEMENT
CONVERGENCE
CONFIGURATION
LENS
QUICK ACCESS KEYS
OSD
INTERNAL PATTERNS
Select with ↑ or ↓
then
to return
Menu 8-3
2. Press ENTER to select.
The input slots menu will be displayed.
INPUT SLOTS
Slot Module type [config]
1.
RGB-SS [CV]
2. RGB-SOG
3. SDI
4. SDI
______________
1. DVI OUTPUT [DVI input]
Select with ↑ or ↓
then
to return
Menu 8-4
Possible results for the fixed input slots (1&2).
Source Indication
Video or S-Video Video
S-video
RGB analog RGB-SS[CV] : separate sync is composite video on H/C input
RGB-SS[cS or HS&VS]: separate sync is composite sync or horizontal and vertical sync
RGB-SOG : sync on green
Component Video Component video - SS : Component video with separate sync
Component video - SOY : Component video with sync on Y
Component video - 3LSS : Component video with 3 level separate sync.
Component video - 3LSOY : Component video with 3 level syns on Y.
RGB analog with
tri-level-sync RGB-SS[3LSS] : RGB with separate Tri level sync.
RGB3L-SOG[3LSOY]: RGB with Tri-level sync on green.
DVI DVI
Possible results for input 3 and 4
SDI Serial digital input
HD SDI high definition digital input
Digital Video Decoder VIDEO[VIDEO]
VIDEO[S-VIDEO]
VIDEO[YUV]
What if a switcher is connected to the projector ?
If a RCVDS (switched on) or VS05 is connected to the projector, it will be also indicated on the menu by adding +800 peripheral.
