A. Standard Source set up Files
A. STANDARD SOURCE SET UP FILES
A.1 Table overview
Table overview
The following standard source files are pre-programmed in the projector.
Name 1 Resolu-
tion
2
Fvert
Hz 3
FHor
kHz 4
Fpix
MHz 5
Ptot 6 Pact 7 Ltot 8 Lact 9
1600_48V 1600x600i 48,040 62,500 135,000 2160 1600 651 600
1600_60V 1600x1200 60,000 75,000 162,000 2160 1600 1250 1200
1600_65V 1600x1200 65,000 81,250 175,500 2160 1600 1250 1200
1600_70V 1600x1200 70,000 87,500 189,000 2160 1600 1250 1200
8514_A 1024x384i 43,479 35,522 44,900 1264 1024 409 384
CGA 640x200 59,924 15.700 14.318 912 640 262 200
COMPUSC4 1024x480i 29,945 30,694 39,779 1296 1024 512 480
DVI_LOOP 1400x1050 56,005 63,902 107,866 1688 1400 1141 1050
ED 735x480 59,943 31,470 28,638 910 735 525 480
EGA 640x350 59,702 21,851 16,257 744 640 366 350
EWS_50 1280x1024 50,000 52,350 87,948 1680 1280 1047 1024
EWS_60 1280x1024 60,000 63,900 107,352 1680 1280 1065 1024
EWS_60V 1280x1024 60,282 63,657 110,000 1728 1280 1056 1024
EWS_72 1280x1024 72,000 76,968 130,076 1690 1280 1069 1024
EWS_75 1280x1024 75,025 79,976 135,000 1688 1280 1066 1024
FMR 640x400i 42,323 36,440 28,570 784 640 431 400
FMTO_2 640x400 55,370 24,370 21,056 864 640 440 400
HD_24P 1920x1080 24,000 27,000 74,250 2750 1920 1125 1080
HD_24SF 1920x540 48,043 27,000 74,250 2750 1820 562 540
HD_25I 1920x540I 25,000 28,125 74,250 2640 1920 563 540
HD_25P 1920x1080 25,000 28,125 74,250 2640 1920 1125 1080
HD_30I 1920x540I 30,000 33n750 74,250 200 1920 563 540
HD_30I_2 1920x517I 30,000 33,750 74,250 2200 1920 563 517
HD_30P 1920x1080 30,000 33,750 74,250 2200 1920 1125 1080
HD_60P 1920x720 60,000 45,000 74,250 1650 1280 750 720
HDMAC 1252x570i 25,020 31,250 39,125 1252 1024 625 570
1. Name: name of file, contains the settings.
2. Resolution: image resolution, when followed by ..i means interlaced.
3. Fvert Hz: vertical frame frequency of the source
4. FHor kHz: horizontal frequency of the source
5. Fpix MHz: pixel frequency
6. Ftot : total pixels on one horizontal line.
7. Pact: active pixels on one horizontal line.
8. Ltot: total lines in one field
9. Lact: active lines in one field.
R5976654 SLM R12+ 27/01/2005 133
