8. Installation Mode
3. Push the cursor key ↑ or ↓ to highlight Highlighted item color.
OSD
HIGHLIGHT ITEM COLOR [red]
MENU POSITION [Default]
Select with ↑ or ↓
then
to return
Menu 8-33
4. Press ENTER to toggle between Yellow, Red and Blue.
8.11.2 Menu Position
How to change
1. Push the cursor key ↑ or ↓ to highlight OSD.
INSTALLATION
INPUT SLOTS
800 PERIPHERAL
SOURCE SWITCHING
NO SIGNAL
CONTRAST ENHANCEMENT
CONVERGENCE
CONFIGURATION
LENS
QUICK ACCESS KEYS
OSD
INTERNAL PATTERNS
Select with ↑ or ↓
then
to return
Menu 8-34
2. Press ENTER to select.
3. Push the cursor key ↑ or ↓ to highlight Menu Position.
OSD
HIGHLIGHT ITEM COLOR [red]
MENU POSITION [Default]
Select with ↑ or ↓
then
to return
Menu 8-35
4. Press ENTER to toggle between [DEFAULT] and [CENTER].
DEFAULT menus displayed in the center, adjustment boxes displayed in the corner.
CENTER menus and adjustment boxes displayed in the center of the image.
8.12 Internal Patterns
What can be done with these internal patterns?
The projector is equipped with different internal patterns which can be used for measurement purposes.
R5976654 SLM R12+ 27/01/2005 107
