2. Packaging and Dimensions
Save this carton box , it can be used to repack the lamp when you ever have to transport your projector.
2.4 Lens Packaging
Way of Packaging
Lenses are supplied as an individual item.
They are packed in a carton.
2.5 Projector Dimensions
Overview
•
•
Projector Dimensions (Inclusive Dust Filters)
2.5.1
Projector Dimensions
Dimensions
The value of the projector dimensions is indicated in mm.
Conversion to inches: 24.5 mm = 1 mm
372,
7
466
83
373
0
456
64,5
520,5
162
38
418
118
64,
5
AIR IN
AIR OUT
IR-receiver
FRONT VIEW
Image 2-2
Front view dimensions
8
R5976654 SLM R12+ 27/01/2005
