73
REPLACEMENT PARTS
ELECTRIC BOOSTER 70˚ RISE
( SIDE MOUNTED BOOSTER)
Fig. 39 Part
Item No.
No. Part Description Qty
1 108576 Cover Booster No Cut Out ............................................................ 2
* 2 111334 Heater 9kW (208V, 240V) (After S/N 82570) .............................. 5
108580 Heater 9kW (208V-240V) (Prior to S/N 82569)............................ 5
111305 Heater 9kW (230V) (After S/N 82570) ........................................ 5
111334 Heater 9kW (380V)........................................................................ 5
111305 Heater 9kW (415V)........................................................................ 5
108579 Heater 9kW (480V)........................................................................ 5
111122 Heater 9kW (575V)........................................................................ 5
3 111118 Cap 3/4NPT Brass.......................................................................... 2
4 102505 Plug 3/4NPT Brass ........................................................................ 2
5 305407 Booster Assy ................................................................................ 2
6 100734 Bolt 1/4-20 x 1" Hex Head ............................................................ 2
7 109682 Cover (Box) Moplenx .................................................................... 1
8 109069 Thermostat w/Capillary.................................................................. 3
9 100141 Nut, Grip 1/4-20 ............................................................................ 2
10 314102 Dual Thermostat Box .................................................................... 1
11 101248 Strainer Line 1" Bronze ................................................................ 1
12 101000 Nipple Close 1NPT Brass .............................................................. 5
13 100269 Valve Pressure Reducing 1" .......................................................... 1
14 101026 Tee Red 1 x 1 x 1/2 Brass .............................................................. 1
15 102388 Bush Red 1/2 x 1/4 Brass (Not Shown) ........................................ 1
16 100123 Cock Gauge 1/4.............................................................................. 1
17 100135 Pressure Gauge 0-60 PSI .............................................................. 1
18 109765 Overlay Pressure Gauge ................................................................ 1
19 111438 Valve 1" HW .................................................................................. 1
20 108516 Coil, Valve ...................................................................................... A/R
21 109904 Kit Repair 1" Stm-Water ................................................................ A/R
22 102450 Elbow Street 1 x 90 Brass .............................................................. 2
23 102551 Union 1NPT Brass ........................................................................ 1
24 102451 Elbow Red 1 x 3/4 x 90 Brass ...................................................... 2
25 102651 Nipple 3/4 x 2 Brass ...................................................................... 2
26 110562 Thermostat, Fixed Snap ................................................................ 2
27 107966 Nut, Grip 10-32 w/Nylon Insert .................................................... 4
28 106460 Screw 7-32 x 3/8 Round Head ...................................................... 4
29 110930 Cover, Booster Thermostat Box .................................................... 2
30 103217 CND Sealtite 90˚ 1/2" .................................................................... 2
31 107966 Nut, Grip 10-32 w/Nylon Insert .................................................... 4
32 107033 Washer .028 x .437 x .047 ............................................................ 4
33 110929 Box Booster Thermostat ................................................................ 2
34 100184 Nipple Close 3/4NPT Brass .......................................................... 2
35 102444 Elbow Street 3/4 x 90 .................................................................... 2
36 109879 Fitting Compression 7/8OD x 3/4MPT Brass .............................. 2
37 XXXXX Copper Tubing (Call Factory to Confirm Application) ................ A/R
38 102525 Tee Red 3/4 x 1/2 x 3/4 Brass ........................................................ 1
39 104682 Thermometer 1/2"NPT Stem ........................................................ 1
40 108296 Union 1C x 1MPT.......................................................................... 1
