REPLACEMENT PARTS
WASH & RINSE ASSEMBLIES
Fig. 26 Part
Item No.
No. Part Description Qty
1 109837 Retaining Screw ............................................................................ 1
2 110679 Bearing, Rinse Arm........................................................................ 2
3 107336 Screw M4 x 12mm Pan Head ........................................................ 12
4 109500 Nozzle 1/8 NPT.............................................................................. 6
5 106407 Washer Lock 3/8 Split.................................................................... 6
6 110193 Nozzle top Rinse Arm.................................................................... 6
7 108021 O-ring ............................................................................................ 8
8 107328 Plug Wash Arm .............................................................................. 2
9 107337 Nut Plain M4 .................................................................................. 12
10 107332 Nozzle Bottom .............................................................................. 6
11 109333 Threaded Ring NS.......................................................................... 1
12 109685 Retainer Ring ................................................................................ 1
13 109684 Bearing PP28 Wash Arm................................................................ 1
14 108442 Bolt M5 x 15mm Filister Head ...................................................... 16
15 109503 Nozzle NS PPW ............................................................................ 4
16 108444 Nozzle Bottom .............................................................................. 4
17 108441 Nut Hex M5.................................................................................... 16
18 108447 Cap 1-1/4 Plastic ............................................................................ 4
19 108445 Cap Adapter.................................................................................... 4
20 108446 Nozzle Top...................................................................................... 4
21 109332 Spindle Wash Arm.......................................................................... 2
22 109331 Wash Arm Support ........................................................................ 2
23 109312 Standpipe Weld .............................................................................. 1
24 100740 Bolt 5/16-18 x 1" Hex Head .......................................................... 4
25 100738 Bolt 1/40-20 x 1" Hex Head .......................................................... 2
26 107967 Nut Grip 1/4-20 w/Nylon Insert .................................................... 2
27 109303 Gasket 1-5/16 ID x 3/4OD x 1/8TK .............................................. 1
28 109299 Final Rinse Pipe Weld .................................................................... 1
29 313212 Bracket Standpipe .......................................................................... 1
30 112318 Screw 1/4-20 x 1/2 Hex Washer Head .......................................... 2
31 100141 Nut Grip 1/4-20 SST ...................................................................... 2
32 109304 Gasket 3"SQ 15/16ID x 1/8TK ...................................................... 1
--- 405902 Rinse Arm Assy PP28 W/Bearings (Includes items 2-10)
--- 900786 Kit*Nozzle PP28 Rinse Complete (Includes items 3-7, 9-10)(Makes up
one complete nozzle assembly)
--- 405903 Wash Arm Assy PP28 w/Bearings (includes items 12-20)
--- 900743 Kit*Wash Arm Rebuild PP28 (Includes items 12-20)(Complete rebuild
of arm components only, does not include spray pipe)
