REPLACEMENT PARTS
TANK COMPONENTS
(ELECTRIC HEAT)
Fig. 29 Part
Item No.
No. Part Description Qty
1 107966 Nut Grip 10-32 w/Nylon Insert...................................................... 2
2 109682 Cover (Box) Moplenx .................................................................... 1
3 100212 Screw 10-32 x 3/4 Truss Head ...................................................... 2
4 110561 Thermostat, Hi-Limit .................................................................... 1
5 109069 Thermostat w/Capillary.................................................................. 1
6 107966 Nut Grip 10-32 w/Nylon Insert...................................................... 4
7 107967 Nut Grip 1/4-20 w/Nylon Insert .................................................... 4
8 100280 Transformer 250V 240/480:120/240.............................................. 1
9 201041 Washer 7/8 x 1-3/16 x 1/8.............................................................. 3
10 100547 Locknut 1/2NPT SST Forged ........................................................ 3
11 108417 Nut 1/2" Plastic .............................................................................. 2
12 109034 Washer 13/16 x 1-3/16 Fiber.......................................................... 2
13 108418 Plug 1/2" Plastic ............................................................................ 2
14 111151 C-Clip Float Switch (Included in item 15) .................................... A/R
15 111019 Dual Float Switch .......................................................................... 1
16 107589 Washer Lock 1/2" External ............................................................ 1
17 104584 Nut Plain 1/2-13 Hex SST ............................................................ 1
--- 110750 Float Switch Gasket (Not Shown) ................................................ 1
18 108391 Thermometer 4' .............................................................................. 1
19 108345 Gasket 3 x 3 x 1/8" ........................................................................ 1
20 109751 Heater 10kW (208-220V, 380V) .................................................... 1
107844 Heater 10kW (230-240V) .............................................................. 1
107846 Heater 10kW (460-480V) .............................................................. 1
111120 Heater 10kW (575V)...................................................................... 1
21 308949 Box Electric Stamped Flange ........................................................ 1
22 109683 Flange Plastic ................................................................................ 1
23 112257 O-Ring ............................................................................................ 1
A HEATER ELEMENT HARDWARE
100154 Nut Plain 5/16-18 .......................................................................... 4
106013 Washer Lock 5/16 Split.................................................................. 4
100740 Bolt 5/16-18 x 1" Hex Head .......................................................... 4
102376 Washer Flat 5/16-18 ...................................................................... 4
B BLOCK FLANGE HARDWARE
100740 Bolt 5/16-18 x 1" Hex Head .......................................................... 4
102376 Washer 5/16 x 3/4 x 1/16 .............................................................. 8
100154 Nut Plain 5/16-18 .......................................................................... 4
106013 Washer Lock 5/16 Split.................................................................. 4
