71
REPLACEMENT PARTS
ELECTRIC BOOSTER 40˚ RISE
(MOUNTED UNDER TANK)
Fig. 38 Part
Item No.
No. Part Description Qty
1 108576 Cover Booster No Cut Out ............................................................ 1
2 107967 Nut, Grip 1/4-20 w/Nylon Insert.................................................... 7
3 106026 Washer, Flat 1/4" ............................................................................ 7
4 111334 Heater 9/12kW (208V, 240V, 380V) (After S/N 82569)................ 3
108580 Heater 9kW (208V, 240V) (Prior to S/N 82568) .......................... 3
* 111235 Heater 5/6.6kW (208V, 240V) ...................................................... 1
111305 Heater 9kW (230V)........................................................................ 3
108579 Heater 9kW (480V) ...................................................................... 3
111122 Heater 9kW (575V)........................................................................ 3
5 111118 Cap 3/4" NPT Brass ...................................................................... 1
6 102470 Nipple 3/4 x 3 Brass ...................................................................... 1
7 102451 Elbow 1 x 3/4 x 90 Brass .............................................................. 2
8 102551 Union 1NPT Brass ........................................................................ 1
9 102540 Elbow Street 1 x 90 Brass .............................................................. 1
10 101000 Nipple Close 1NPT Brass .............................................................. 5
11 111438 Valve 1" hw .................................................................................. 1
12 108516 Coil, Valve ...................................................................................... A/R
13 109904 Kit Repair 1" Stm-Water ................................................................ A/R
14 101026 Tee Reducing 1 x 1 x 1/2 .............................................................. 1
15 102767 Nipple 1 x 5 Brass.......................................................................... 1
16 100269 Valve Pressure Reducing 1" .......................................................... 1
17 101248 Strainer Line 1" Bronze ................................................................ 1
18 102388 Bushing Red 1/2 x 1/4 Brass ........................................................ 1
19 100123 Cock Gauge 1/4.............................................................................. 1
20 100135 Pressure Gauge 0-60 PSI .............................................................. 1
21 109765 Overlay Pressure Gauge ................................................................ 1
22 100734 Bolt 1/4-20 x 12/ Hex Head .......................................................... 4
23 108296 Union 1C x 1MPT.......................................................................... 1
24 203152 Tubing 1 x 10 Copper .................................................................... 1
25 109069 Thermostat w/Capillary.................................................................. 1
26 109900 Tee Red 1C x 1/2F x 1C Brass ...................................................... 1
27 103217 Connector, Sealtite 1/2 x 90 .......................................................... 1
28 110930 Cover, Box...................................................................................... 1
29 106460 Screw 6/32 x 3/8 Round Head ...................................................... 4
30 107966 Nut, Grip 10-32 w/Nylon Insert .................................................... 4
31 107033 Washer, Flat #10 ............................................................................ 2
32 110929 Box, Thermostat ............................................................................ 1
33 110562 Thermostat, Hi Limit .................................................................... 1
--- 110563 Compound Heat Sink .................................................................... A/R
34 305407 Tank, Booster ................................................................................ 1
35 102505 Pipe Plug 3/4NPT Brass ................................................................ 1
36 100184 Nipple Close 3/4NPT Brass .......................................................... 1
A ELEMENT HARDWARE (per element)
109985 Seal, Electric Heater Flanged ........................................................ 1
100003 Nut, Plain 1/4-20 ............................................................................ 3
106482 Washer, Lock 1/4 Split .................................................................. 3
*When less than 3 elements used in booster tank, requires the following to block off unused
element holes:
109458 Block Off, Heater .......................................................................... A/R
112257 O-ring ............................................................................................ A/R
100003 Nut, Plain 1/4-20 ............................................................................ 3
106482 Washer, Lock 1/4 Split .................................................................. 3
