61
REPLACEMENT PARTS
PIPING WITH STEAM BOOSTER
Fig. 34 Part
Item No.
No. Part Description Qty
1 108342 Elbow 1C x 90 Copper .................................................................. 1
2 Nipple (Call Factory w/Length for Correct Part) .......................... A/R
3 108296 Union 1C x 1MPT.......................................................................... 1
4 102532 Tee Red 1 x 1/2 x 1 ........................................................................ 1
5 102504 Plug 1/2NPT Square Head ............................................................ 2
6 309602 Bracket Support Pipe .................................................................... 1
7 101000 Nipple Close 1NPT Brass .............................................................. 4
8 102388 Bush Red 1/2 x 1/4 Brass .............................................................. 1
9 100123 Cock Gauge 1/4.............................................................................. 1
10 100135 Pressure Gauge 0-60PSI ................................................................ 1
11 109765 Overlay Pressure Gauge ................................................................ 1
12 102551 Union 1NPT Brass ........................................................................ 1
13 102764 Nipple 1 x 4 Brass.......................................................................... 1
14 102540 Elbow Street 1 x 90 Brass .............................................................. 2
15 102556 Vacuum Breaker 1" ........................................................................ 1
16 108352 Repair Kit 1" .................................................................................. A/R
17 102762 Nipple 1 x 3-1/2 ............................................................................ 1
18 111438 Valve 1" HW .................................................................................. 1
19 108516 Coil, Valve ...................................................................................... A/R
20 109904 Kit Repair 1" Stm-Water ................................................................ A/R
21 101026 Tee Red 1 x 1 x 1/2 Brass .............................................................. 2
22 100585 Locknut .......................................................................................... 1
23 100734 Bolt 1/4-20 x 1/2 Hex Head SST .................................................. 1
24 100141 Nut Grip 1/4-20 SST (Not Shown) ................................................ 1
