6540 Series Operations Manual Rev_I.docx 4/7/2014 28
Reviewing Test Setup
The following steps are how to view the test setup during a test or before a completed test is acknowledged.
Once a test is running, the test setup can be viewed but not changed.
1. From the main screen, press desired light test setup (UVA) or (VIS) button. (UVA used in
example)
2. Press (TEST SETUP) button. The exposure test and timed test text is gray and corresponding
buttons are suppressed. In this example, an exposure test is running.
3. Press the (NEXT) button. The exposure level for the total test will be displayed. If a timed test is
running, the total test time will be displayed.
‘Check’ indicating
test running
