UL4000
Ultra-Lok
Tool
Setup
Instructions
Note: Some components are not visible in this illustration.
Tension Screw
NOTE: Alignment is critical for proper tool function.
Safety Clutch
When installing the tool on the drill, be careful to align the end of the Tension Screw with
the slot in the end of the safety clutch, as shown above.
