Rev. A3, 10/08 DCR-1003 and DCR-1004
43
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Specifications
DCR-1003 DCR-1004
Outputs 4 relays (5 A 110 VAC) 4 relays (5 A 110 VAC)
with 4-20 mA or 0-20 mA
Supply Voltage 110-220 VAC 110-220 VAC
Total Current Draw 0.1 A 0.1 A
Housing fiberglass fiberglass
Rating NEMA 4X, IP65 NEMA 4X, IP65
Dimensions 8.5 x 6.5 x 4.25 in. 8.5 x 6.5 x 4.25 in.
(216 x 165 x 108 mm) (216 x 165 x 108 mm)
Resolution maximum of .01 in. maximum of .01 in.
(.25 mm) (.25 mm)
Display 4 character digital LED 4 character digital LED
Operating Temp. -30 to 50°C -30 to 50°C
Connector Terminal Strip Terminal Strip
Sample Rate 1-12 Hz 1-12 Hz
Programmable Settings microprocessor microprocessor
controlled modes controlled modes
Sensor Connector F connector F connector
