17 Trip 2 Type Range = 0 - 7 Selects the type of function
Default = 0 function Trip 2 will perform
18 Begin Trip 3 Units = mode 1/mode 3 Sets the begin point
Default = 3.50 ft. of Trip 3
19 End Trip 3 Units = mode 1/mode 3 Sets the end point
Default = 3.90 ft. of Trip 3
20 Trip 3 Type Range = 0 - 7 Selects the type of function
Default = 0 Trip 3 will perform
21 Begin Trip 4 Units = mode 1/mode 3 Sets the begin point
Default = 4.0 ft. of Trip 4
22 End Trip 4 Units = mode 1/mode 3 Sets the end point of
Default = 4.40 ft. of Trip 4
23 Trip 4 Type Range = 0 - 7 Selects the type of function
Default = 0 Trip 4 will perform
