Rev. A3, 10/08 DCR-1003 and DCR-1004
39
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Quick Reference Sheet
MODE DESCRIPTION PARAMETERS
Operation
1 Units ________________________
2 Decimal Point ________________________
3 Operating Mode ________________________
4 Sensitivity ________________________
5 Blanking ________________________
6 Pulses ________________________
Filtering
7 Sample Rate ________________________
8 Samples Averaged ________________________
9 Out-of-Range Sample ________________________
10 Out-of-Range Span ________________________
11 Loss of Echo Delay ________________________
Relay
12 Begin Trip 1 ________________________
13 End Trip 1 ________________________
14 Trip 1 Type ________________________
15 Begin Trip 2 ________________________
16 End Trip 2 ________________________
17 Trip 2 Type ________________________
18 Begin Trip 3 ________________________
19 End Trip 3 ________________________
20 Trip 3 Type ________________________
21 Begin Trip 4 ________________________
22 End Trip 4 ________________________
23 Trip 4 Type ________________________
Analog
24 Analog Output ________________________
25 0 or 4 mA Distance ________________________
26 20 mA Distance ________________________
