MODE DESCRIPTION PARAMETERS EXPLANATION
38 Constant Above Range = 0 - 9999 Sets the portion of the multiplier
Decimal Point Default = 1 (K) above the decimal point,
used for converting distance to
flow
39 Constant Below Range = .0000 - .9999 Sets the portion of the multiplier
Decimal Point Default = .0000 (K) below the decimal point,
used for converting distance to
flow
40 Decimal Point Range = 0000. - 0.000 Sets the decimal point position
Default = 00.00 of the display. Same as mode 4.
41 Span Units = mode 1 Sets the measured distance
Range = 0.000 - 9999 from .5" behind the DST
Default = 12.00 feet face to the zero flow level
42 Exponent Above Range = 0 - 9999 Sets the portion of the exponent
Decimal Point Default = 1 (X) above the decimal point,
used to convert distance to flow
43 Exponent Below Range = .0000 - .9999 Sets the portion of the exponent
Decimal Point Default = 0 (X) below the decimal point,
used to convert distance to flow
