AirLive WL-1200CAM User’s Manual
31
according to the actual signal strength and quality.
Authentication Select the wireless authentication here, and this setting must be the
same with the wireless access point you selected.
When you select a wireless access point from the list, it ’s authentication
type will be selected automatically, and you should not modify it or you
will not be able to connect to the wireless access point you selected.
Available options are: None (no authentication), Open System, Shared
Key System, WPA-PSK, WPA2-PSK, and WPANone (the last one is only
for Adhoc).
Encryption Type Select the wireless encryption type here, and this setting must be the
same with the wireless access point you selected.
When you select a wireless access point from the list, it ’s encryption type
will be selected automatically, and you should not modify it or you will not
be able to connect to the wireless access point you selected.
Available options are: None, WEP, TKIP and AES. The options available
here will vary depends on the authentication type you selected above. If
an authentication type does not support need encryption, this field will be
grayed out.
WPA Pre-Shared
Key
Input the WPA pre-shared key here.
This field is only available when authentication type is WPA-PSK or
WPA2-PSK, and will be grayed out when other authentication type is
selected.
WEP Key Length Please select the key length when you use WEP encryption. Available
options are 64-bit and 128-bit.Selecting ‘128-Bit’ is safer, however, it
would make the network a little bit slower.
If the key length is 64-bit, you should input 10 HEX characters or 5 ASCII
characters, like 112233aabb (HEX) or MYWEP (ASCII).
If the key length is 128-bit, you should input 26 HEX characters or 13
ASCII characters, like 11223344556677889900abcdef (HEX) or
myweppassword (ASCII).
WEP Key Format Select the Key Format of WEP key here. Available options are ‘HEX’ and
‘ASCII’.
When you select
‘HEX’ WEP key format, you can only use numbers (0 to
9), and alphabet a to f as WEP key; when you select ‘ASCII’ WEP key
format, you can use all alphanumerical characters, and is case sensitive.
Default Key Select the default key set that is IP camera should use against the
wireless access point when WEP encryption is used.
Available options are 1 to 4.
WEP Key 1 Input the 1
st
set of WEP key here. At least a set of WEP key is required
and you should use 1
st
WEP key if you only have one WEP key.
WEP Key 2 Input the 2
nd
set of WEP key here.
WEP Key 3 Input the 3
rd
set of WEP key here.
WEP Key 4 Input the 4
th
set of WEP key here.
Click ‘Apply’ to save settings and make the new settings take effect.
