AirLive RS-3000 - Manual (Page 44)

 PPTP (European User Only) (Figure 5-11):
1. Select PPTP (European User Only)
2. Enter User Name as an account.
3. Enter Password as the password.
4. If the MAC Address is required for ISP then click on Clone MAC Address to obtain
MAC IP automatically.
5. Select Obtain an IP address automatically or Use the following IP address
provided by ISP.
6. Hostname: Enter the hostname provided by ISP.
7. Domain Name: Enter the domain name provided by ISP.
8. If user selects Use the following IP address, please enter IP Address, Netmask, and
Default Gateway.
9. Enter PPTP server IP address as the PPTP Gateway provided by ISP.
10. Enter Max. Downstream Bandwidth and Max. Upstream Bandwidth (According to
the flow applied by user)
11. Select BEZEQ-ISRAEL (Israel User Only)
12. Select Ping and HTTP
13. Click OK (Figure 5-12)
You can choose Service-On-Demand for WAN Interface to connect automatically when
disconnect; or to set up Auto Disconnect if idle (not recommend)
42
