In this section, the Administrator can set up the IP addresses for the office network.
The Administrator may configure the IP addresses of the LAN network, the WAN 1/2 network, and the
DMZ network.
The Netmask and gateway IP addresses are also configured in this section.
Define the required fields of Interface
LAN: Using the LAN Interface, the Administrator can set up the LAN network of RS-3000.
Ping: Select this function to allow the LAN users to ping the Interface IP Address.
HTTP: Select to enable the user to enter the WebUI of RS-3000 from Interface IP.
WAN: The System Administrator can set up the WAN network of RS-3000.
Balance Mode:
 Auto: The RS-3000 will adjust the WAN 1/2 utility rate automatically according to the
downstream/upstream of WAN. (For users who are using various download bandwidth)
 Round-Robin: The RS-3000 distributes the WAN 1/2 download bandwidth 1:1, in other words, it
selects the agent by order. (For users who are using same download bandwidths)
 By Traffic: The RS-3000 distributes the WAN 1/2 download bandwidth by accumulative traffic.
 By Session: The RS-3000 distributes the WAN 1/2 download bandwidth by saturated
connections.
 By Packet: The RS-3000 distributes the WAN 1/2 download bandwidth by accumulated packets
and saturated connection.
 By Source IP: The RS-3000 distributes the WAN 1/2 connection by source IP address, once the
connection is built up, all the packets from the same source IP will pass through the same WAN
interface.
 By Destination IP: The RS-3000 will allocate the WAN connection corresponding to the
destination IP, once the connection is built up, all the packets to the same destination IP will pass
through the same WAN interface. The connection will be re-assigned with WAN interface when the
connections are stopped.
