C C C h h h a a a p p p t t t e e e r r r 2 2 2 5 5 5 W W W a a a k k k e e e o o o n n n L L L a a a n n n
Wake on Lan (WOL) function works to power on the computer remotely. The computer’s network card
must also support WOL function, when it receive the waked up packets and the computer will auto boot
up.
Normally the broadcast packets are not allowed to transfer within Internet, but user can login RS-3000
remotely and enable Wake on Lan function to boot up the LAN computer.
To configure Wake on Lan function in RS-3000
STEP 1
﹒ Select Setting in Wake on Lan, and enter MAC Address to specify the computer who needs
to be booted up remotely. User can press Assist to obtain the MAC Address from the table
list. (Figure25-1)
Figure 25-1 Wake on Lan Setting
STEP 2
﹒ User only needs to press Wake Up button to boot up the specific LAN computer. (Figure 25-2)
Figure 25-2 Complete Wake on Lan Setting
251
