AiM LCU-One CAN + Analog ver 1.05 - Manual (Page 30)

LCU ONE-CAN+Analog
User manual
Release 1.05
www.aim-sportline.com 29
1 2 3 4 5 6
7 8
16 15 14 13
12 11 10 9
18 17
Materiale / Material Q.tà / Q.ty Rif. / Ref.
Progettato da / Designed by Contr. da / Ckd. by Approvato da / Approved by Nome file / File name Data / Date
N. articolo / Item N.
Scala / Scale
Foglio / Sheet Rev. / Rev.
Titolo / Title
N. disegno / Drawing N.
N.rev. / Rev. N. Descrizione / Description Data / date Firma / Sign Contr. da / Ckd. by
PINOUT LCU-ONE CAN+Analog
Pinout LCU-ONE CAN+Analog
1 di 1
1
2
3
4
5
6
7
8
9
16 pin AMP male connector pinout
GND (power)
+V batt
H-
IP-/VS-
VS+
RS232RX PC
+VB
GND (CAN)
H+
10
11
12
13
14
15
16
17
18
Rcal
IP+
RS232TX PC
CAN+
CAN-
nc
GND (signal)
Lambda Out
GND (RS232)
L.I.
