Appendix – Part numbers and technical drawings
1 3
“A” – Part number of LCU-ONE CAN+Analog complete kit
WARNING: each kit contains one only extension for each communication
protocol and depending on the connector (plastic or metallic) that is wished on
the wiring and that is in any case included in the kit, kit part number is going to
change following this table.
LCU-ONE CAN+Analog
complete kit includes:
LCU-ONE CAN+Analog
Bosch LSU 4.9 lambda probe
CAN+Analog + RS232 wiring
Extension with plastic RS232 Deutsch connector
CAN line termination cap
X08LCKACR
Metallic CAN + metallic Analog X08LCKACR710
Plastic CAN + metallic Analog X08LCKACR711
Metallic CAN + plastic Analog X08LCKACR610
Plastic CAN + plastic Analog X08LCKACR611
1 4
“B” – Spare parts
BOSCH LSU 4.9 Lambda probe X05LSU490
CAN + Analog + RS232 wiring V02359040
Analog extension plastic Deutsch Binder 712 (metallic) V02359070
Analog extension plastic Deutsch Binder 719 (plastic) V02359060
Extension plastic RS232 Deutsch connector V02539130
CAN extension plastic Deutsch Binder 712 (metallic) V02359100
CAN extension plastic Deutsch Binder 719 (plastic) V02359110
CAN termination cap V02359080
