2N® EasyGate Pro parameters configuration
3.1
26
Installation and setting of EasyGate PCManager (Win7)
1. Connect EasyGate to the PC using USB connection. EasyGate must be switched
off.
2. After connecting is the virtual serial port in PC installed automatically. I case,
that the port doesn’t install automatically and unknown device is detected,
install drivers by using file: Drivers/win/CDM20814_Setup.exe.
3. Find the number of virtual port using Device manager. Look at setting of COM
ports and find port marked as USB Serial Port(COMn).
4. Install PCManagerSmG from CD.
5. Run EasyGate PCManager, select the language on the upper bar.
6. In menu Program select Setup. Set the COM port – local and select COM port
number according information from point 3.
Using of PCManager - basic
1. The main purpose of PCManager UNI is setting of configuration and upgrade
firmware of EasyGate.
2. When the configuration in EasyGate should be changed, the configuration must
be first loaded from EasyGate, than edited using PCManager and finaly saved
back to EasyGate.
3. The groups of parameters are listed is in the left window of the program. All
parameters are described in next part of this manual. There is interactive help
in PCManager for all parameters.
4. When you start with any operation which needs communication with EasyGate,
the gateway must be switched to special programming mode. PCManager will
show you the demand to switch the gateway off and on to set it to this mode.
Further Data Handling Options
In addition to the EasyGate memory, settings can be saved in a PC file and reloaded
into the PCManager. This is recommended for backing up of current configurations or
saving the same configuration to another Easy Gate unit.
Caution
n
The table Security includes the PIN code and service password. These
parameters have a special handling. They are not saved in a PC file for
security reasons. If you load a PC file into the PCManager UNI and then
into EasyGate, the PIN and service password should not change unless
you change them manually before saving.
Caution
n
All tables are filled-in with default values when PCManager UNI starts. It is
recommended to load data from EasyGate before parameters
programming and saving. If you only save data after PCManager UNI
start, all parameters except the PIN and service password in the EasyGate
memory will have default values.
