6.7 4017
Transmission:
6.7 TROUBLESHOOTING
This section provides an easy reference guide covering
the most common problems that may occur during
operation of the transmission.
Note: Contact the JLG Service Department if internal
transmission repair is required during the warranty
period.
The transmission should be checked, serviced and
repaired only by experienced service technicians who are
aware of all safety instructions and particular component
features.
6.7.1 Transmission Troubleshooting
Problem Cause Remedy
1. Transmission will not engage
or will not shift properly.
1. Oil level too high or low.
2. Transmission control lever not
functioning properly and/or a
fault in the wiring harness.
3. Transmission valve body
solenoids not functioning
properly.
4. Pilot-operated shift valves not
operating properly.
5. Pump output pressure low.
6. Clutch piston o-rings damaged.
7. Clutch discs worn or damaged.
8. Coupling shafts or gear teeth
damaged.
1. Fill transmission to correct level.
(Refer to the appropriate
Operator & Safety Manual.)
2. Refer to Section 9.5.1, “Cab
Harness Electrical Schematic.”
3. Refer to Section 9.5.1, “Cab
Harness Electrical Schematic.”
4. Clean the valve spool and
housing. Replace return spring
as needed.
5. Refer to Section 6.7.1,
“Transmission Troubleshooting,”
Problem 2. “Low or no pump
flow or pressure.”
6. Replace o-rings.
7. Replace clutch discs.
8. Replace couplings.
2. Low or no pump flow or
pressure.
1. Low oil level.
2. Transmission filled with incorrect
oil, or oil contaminated.
3. Pump suction pipe screen
clogged.
4. Central shaft damaged.
5. Pump worn or damaged.
1. Fill transmission to correct level.
(Refer to the appropriate
Operator & Safety Manual.)
2. Drain transmission and fill to
correct level. (Refer to Section
2.4, “Fluids, Lubricants and
Capacities.”)
3. Clean, repair and/or replace
suction pipe.
4. Replace central shaft.
5. Repair or replace pump
assembly.
