9.5 4017
Electrical System
9.4.2 Connector Legend, Relays & Fuses
Connector Legend
No. Type
X1 PCB Power & GND Harness
X2 Instrument Panel Harness
X3 Instrument Panel Harness
X4 Instrument Panel Harness
X5 Cab Harness
X6 Cab Harness
X7 Cab Harness
X8 Cab Harness
X9 Worklight, Radio, Rear Wiper Harness
X10 Front Chassis Harness
X11 Engine Harness
X12 Rear Chassis Harness
X13 Rear Chassis Harness
X14 Optional Trailer(ing) Harness
X15 Joystick Connector
X16 Front Chassis Harness
X17 ESX Harness
X18 ESX Harness
X19 ESX Harness
X21 CAN Diagnostic Connector
X22 Front Chassis Harness
X23 F-N-R & Gear Shifter Harness
X25 RS232 Diagnostic Connector
X26 Tilt Sensor - Not Used
Relays
K1 Key (Power) Relay
K2 Start Interlock Relay
K3 Flasher
K4 Wiper Relay
K5 Work Light Relay
K6 Fuel Solenoid Relay
Engine Compartment Relays & Fuse
Lift Pump Relay
Glow Plug Relay
Starter Relay
Lift Pump & Glow Plug Fuses
Fuses
No. Amp Type
F1 15A Rear Work Lights
F2 15A Cab Heater
F3 7.5A Left Headlight - Low
F4 7.5A Right Headlight - Low
F5 7.5A Left Headlight - High
F6 7.5A Right Headlight - High
F7 7.5A Left Tail & Side Lights
F8 7.5A Right Tail & Side Lights, Display
F9 15A Auxiliary Power Socket
F10 15A Battery Indicator Light
F11 25A ESX Battery
F12 30A Key Switch
F13 15A Spare
F14 10A Brake Lights, Cold Start, Beacon
F15 15A Ignition
F16 20A Rear Wiper
F17 20A Front Wiper
F18 15A Front Work Lights
F19 15A Boom Work Lights
F20 Not Used
F21 25A Air Conditioning
F22 5A Radio
F23 10A Transmission
F24 7.5A ESX Ignition & Sensors
