General Information and Specifications
2.8 4017
2.3.6 Electrical System
Battery:
Type, Rating 12 VDC, Negative (-) Ground, Maintenance Free
Quantity 1
Reserve Capacity 1,000 Cold Cranking Amps @ 0° F (-18° C)
Group/Series Series 31
Alternator 12V, 85 Amps
Fuses - Standard Blade Style:
5 Amps Radio
7.5 Amps Headlights and Tail Lights, ESX Ignition and Sensors
10 Amps Brake Lights, Cold Start, Beacon
15 Amps Rear Work Lights, Cab Heater, Aux Power Socket,
Battery Ind. Light, Dome Light, Spare, Ignition, Front
Work Lights, Boom Work Lights,
20 Amps Rear Wiper, Front Wiper
25 Amps ESX Battery, Air Conditioning
30 Amps Key Switch
Relays:
Key (power) K1
Start Interlock K2
Flasher K3
Wiper K4
Work Lights K5
Fuel Solenoid K6
Relays in Engine Compartment:
Starter
Lift pump
Glow Plug
Inline Fuse:
Lift Pump and Glow Plug
