JLG 110HXER ANSI Parts Manual User Manual
Page 98
2-62
3120637
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
OPTIONAL COLLECTOR RING INSTALLATION
(STANDARD PARTS)
Ref.
201
Not Used
202
0960224
Bushing
2
203
0641418
Bolt 1/4”-20NC x 2 1/4”
2
204
Not Used
1
205
Not Used
206
Not Used
207
3311801
Nut 1/2”-13NC
2
208
3420290
Pin, Drive
2
209
0231047
Guide, Drive
2
210
Not Used
211
0721005
Screw, Machine #10-24NC x 5/8”
4
212
4761400
Lockwasher 1/4”
2
213
1320040
Clamp, Cable
2
214
3911012
Screw, Machine
1
215
4751000
Flatwasher #10
6
216
4761000
Lockwasher #10
5
217
3311001
Nut #10-24NC
5
218
4751400
Flatwasher 1/4”
2
COLLECTOR RING INSTALLATION - MACHINES
WITH SINGLE OR NO AXLE JACK (VARIABLE
PARTS)
0232123
Machines With Single Or No Axle Jack
Ref.
7
0252284
Machines With Dual Axle Jacks
Ref.
3
251
Bracket Weldment Options:
1
0230470
Machines With Single Or No Axle Jack
1
4843822
Machines With Dual Axle Jacks
1
252
Pipe Options:
1
3460065
Machines With Single Or No Axle Jack
1
2180763
Machines With Dual Axle Jacks
1
253
Bushing Options:
1
0230435
Machines With Single Or No Axle Jack
1
0961531
Machines With Dual Axle Jacks
1
254
Collector Ring Assembly Options:
1
3760036
Machines With Single Or No Axle Jack
1
3760108
Machines With Dual Axle Jacks
1
255
Cover Options:
1
1670594
Machines With Single Or No Axle Jack
1
0234721
Machines With Dual Axle Jacks
1
FIGURE 2-19. ROTARY COUPLING AND COLLECTOR RING ASSEMBLY AND INSTALLATION
(CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
