BOOM INSTALLATION (VARIABLE PARTS)
0250051 Standard 100HX Ref. G
0239861 Standard 110HX Ref. G
0252558 110HX with Chip Covers Ref. B
0239862 Standard 110HX+10 & 110HXER Ref. G
0252559 110HX+10 & 110HXER with Chip Covers Ref. B
151 Master Cylinder Assembly Options (See Section 5 for
Breakdown): 1
1681978 100HX & 110HX
1681580 110HX+10 & 110HXER
152 Pin 1
3421586 100HX & 110HX
0236548 110HX+10 & 110HXER
153 Flatwasher, Special 1
4740331 100HX & 110HX
4740006 110HX+10 & 110HXER
154 Fastener Options: 1
0741608 100HX & 110HX (Screw, Flathead 3/8”-16NC x 1”)
0641608 110HX+10 & 110HXER (Bolt 3/8”-16NC x 1”)
155 Lockwasher 3/8” Options: A/R
Not Required 100HX & 110HX 0
4761600 110HX+10 & 110HXER 3
156 Pin Options: 1
3421561 100HX & 110HX
3420085 110HX+10 & 110HXER
157 Pin, Cotter 3/16” x 2 1/2” Options: A/R
Not Required 100HX & 110HX 0
3450610 110HX+10 & 110HXER 2
0236629 HORIZONTAL CUTOUT LIMIT SWITCH
INSTALLATION (RIGHT SIDE) Ref. 3
201 4360057 Switch, Limit 1
202 4761000 Lockwasher #10 2
203 0721014 Bolt #10-2NC x 1 3/4” 2
204 Not Used
205 0200048 Arm, Actuator 1
206 4460049 Connector 1
LUBE LINES INSTALLATION
0239843 100HX & 110HX Ref. A
0239844 110HX+10 & 110HXER Ref. 3
401 2160002 Fitting, Grease 3
402 2220001 Fitting 3
403 to 404 Not Used
405 2750807 Hose 1
406 2200261 Fitting, Nipple 2
FIGURE 2-2. TURNTABLE, BOOM AND CUTOUT SWITCH INSTALLATIONS (4620044 TURNTABLE
MACHINES) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
