SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
57
Bolt Options:
A/R
0641912
4620038 Turntable Machines
9
0642216
4620044 & 4620078 Turntable Machines
8
TURNTABLE BEARING INSTALLATION
0238921
Prior to October 1989
Ref.
D
0250348
October 1989 to Present
Ref.
7
101
0440193
Bearing, Turntable
1
102
Not Used
103
4740004
Washer, Special
80
104
0100019
Loctite #271 (Not Shown)
A/R
105
Not Used
106
0100004
Devcon (Required Prior to December 1992) (Not
Shown)
A/R
107 to 150
Not Used
151
Bolt Options:
40
0682015
Prior to October 1989 (Bolt 5/8”-11NC x 1 7/8”)
(Grade 8)
0682016
October 1989 to Present (Bolt 5/8”-11NC x 2”)
(Grade 8)
0682026
October 1989 to Present (Bolt 5/8” -11NC x 3 1/4”)
(Grade 8)
152
Bolt Options:
40
0682016
Bolt 5/8”-11NC x 2” (Grade 8)
0682018
Bolt 5/8”-11NC x 2 1/4” (Grade 8)(Use with item
106)
TURNTABLE LOCK INSTALLATION (STANDARD
PARTS)
Ref.
201
Not Used
202
3421565
Pin, Snap
1
203
1260017
Chain
9in/23cm
204
3760170
Ring, Quick Release
2
205
3421563
Pin, Locking
1
0239147
TURNTABLE LOCK INSTALLATION (4620038
TURNTABLE MACHINES) (VARIABLE PARTS)
Ref.
—
251
4843052
Bushing Weldment
1
0239842
TURNTABLE LOCK INSTALLATION (4620044 AND
4620078 TURNTABLE MACHINES) (VARIABLE
PARTS)
Ref.
2
251
4843318
Bushing Weldment
1
FIGURE 2-12. SWING DRIVE, BEARING AND LOCK INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
