SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
191 2420187 Dipstick 1
192 4567694 Exhaust Weldment 1
193 0902489 Bracket, Exhaust 1
194 4751500 Flatwasher 5/16" Narrow 2
195 4920967 Harness, Ground 1
196 1320032 Clamp 4
197 3311505 Locknut 5/16"-18NC 2
198 4791600 Starwasher 3/8" 4
199 0641610 Bolt 3/8"-16NC x 1 1/4" 1
200 4921766 Harness, Engine (See Section 7 for Breakdown) 1
201to 209 Not Used
210 4100025 Sleeve, Fiberglass 4ft/1.2m
211 4920385 Wire, Safety A/R
2000157 ENGINE COMPONENTS Ref.
301 7019977 Alternator 1
Use 7027402 Belt, Drive (was p/n 7019979) 1
7019978 Tensioner, Belt 1
302 7016600 Fuel Pump - Electric (Facet) 1
7016601 Filter, Fuel (Used with Facet Pump) 1
303 7019980 Harness, Engine 1
304 Use 7023687 Module, Ignition (was p/n 7019961) 1
305 7012679 Starter (Far Side - Not Shown) 1
306 Use 7021869 Filter, Oil (was p/n 7014501) 1
307 Use 7019988 Carburetor (was p/n 7019974) 1
7019933 Carburetor Repair Kit 1
Use 7000646 Gasket, Carburetor (Base) 1
308 7019976 Flywheel Housing and Coupling Assembly 1
7022180 Ring Gear 1
309 Use 1660249 Coupling (was p/n 7012656) 1
310 7019985 Pump, Water 1
7019982 Tube, Inlet 1
311 7019923 Manifold, Intake (Not Shown) 1
7019924 Manifold, Exhaust (Not Shown) 1
70002307 Gasket, Manifold to Pipe (Not Shown) 1
312 7019981 Sender, Oil Level Indicator (Not Shown) 1
313 7019997 Regulator (Not Shown) 1
SWITCH INSTALLATIONS
0255274 Low Oil Pressure Shutdown Installation Ref. B
0255231 Generator Installation Ref. D
401 2180360 Fitting, Tee 1
Switch, Oil Pressure Options: 1
4360065 Low Oil Pressure Shutdown Installation
4360037 Generator Installation
FIGURE 2-28. FORD LRG-425 ENGINE INSTALLATION - (S/N 35742 TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
