JLG 110HXER ANSI Parts Manual User Manual
Page 152
2-116
3120637
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
HAYES COUPLING INSTALLATION (DESIGN C)
Ref.
0250599
Ford Engines
Ref.
—
0250600
Deutz Engines
Ref.
2
201
1660183
Coupling 1
202
Bolt Options:
6
0641607
Ford Engines (3/8”-16NC x 7/8”)
0701010
Deutz Engines (10mm x 20mm)
203
Lockwasher Options:
6
4761600
Ford Engines (3/8”)
4832000
Deutz Engines (10mm)
204
Adapter, Pump Mounting Options:
1
0080163
Ford Engines (3/8”)
0080164
Deutz Engines (10mm)
205
Bolt Options:
A/R
0641610
Ford Engines (3/8”-16NC x 1 1/4”)
8
0701015
Deutz Engines (10mm x 35mm)
12
206
Lockwasher Options:
A/R
4761600
Ford Engines (3/8”)
8
4832000
Deutz Engines (10mm)
12
3020021
Grease
A/R
1660218
HAYES COUPLING INSTALLATION (FORD
ENGINES WITH DESIGN D)
Ref.
—
301
7012656
Coupling (Design D)
1
Note: Design D not used on Deutz Engines.
FIGURE 2-31. PUMP COUPLING INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
