43 0641508 Bolt 5/16"-18NC x 1" 3
44 4761500 Lockwasher 5/16" 3
45 4751500 Flatwasher 5/16" 3
46 4843963 Hood, Top and Side - Rear (Left Side) 1
47 1780231 Hood, Top and Side - Rear (Right Side) 1
48 0641406 Bolt 1/4"-20NC x 3/4" 9
49 4751400 Flatwasher 1/4" 9
50 3311405 Locknut 1/4"-20NC 9
51 3941405 Screw, Self Tap 1/4"-20NC x 5/8" 7
52 4761400 Lockwasher 1/4" 7
53 2940045 Latch 1
54 0901502 Bracket, Mounting 1
55 3311605 Locknut 3/8"-16NC 4
56 4751600 Flatwasher 3/8" 4
4300034 Stud (Welded on Part - Not Shown) 4
57 1780232 Panel, End 1
58 0641510 Bolt 5/16"-18NC x 1 1/4" 4
59 4751600 Flatwasher 3/8" 4
60 4751500 Flatwasher 5/16" 4
61 3311505 Locknut 5/16"-18NC 4
0250178 ALARM INSTALLATION Ref. B
101 Not Used
102 0140024 Alarm 1
103 4300031 Stud (Welded on Part - Not Shown) 2
104 4751400 Flatwasher 1/4" 2
105 4761400 Lockwasher 1/4" 2
106 3311401 Nut 1/4"-20NC 2
FIGURE 2-37. HOODS AND ALARM INSTALLATION (4620038 TURNTABLE) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
