JLG 110HXER ANSI Parts Manual - Manual (Page 251)

3120637 5-13
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
SECTION 5 CYLINDER
FIGURE 5-6. PLATFORM LEVEL CYLINDER ASSEMBLY (100HX+10 & 110HXER BUILT MAY 1992
TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLY OPTIONS: Ref.
1682753 May 1992 To S/N 29913 Ref. F
1683493 S/N 29913 to Present Ref. A
1683493 CSA - Prior To S/N 33111 Ref. A
1683530 CSA - S/N 33111 To Present Ref. 1/A
1 Barrel Weldment Options:
1682754 May 1992 To S/N 29913 1
1682754 S/N 29913 To S/N 33111 1
1683529 S/N 33111 To Present 1
0961595 Bushing, Bronze 2
2 1682755 Rod Weldment 1
0961182 Bushing, Oilite 2
3 1120305 Retainer 1
4 1681792 Head 1
5 3480167 Piston 1
6 4565913 Spacer 1
7 3300279 Nut 1
8 4640634 Cartridge, Holding Valve 1
2900770 Seal Kit - 4640634 Valve 1
9 2220885 Plug 3/8" 1
10 2220883 Plug 1/4" 2
11 3900170 Setscrew 3/8"-16NC x 3/8" 1
12 Kit Wiper, Rod 1
13 Kit Seal, Rod 1
14 Kit Ring, Wear 1
15 Kit O-Ring 1
16 Kit O-Ring 1
17 Kit Ring, Guide 2
18 Kit Ring, Lock 2
19 to 22 Not Used
23 Cartridge, Holding Valve Options:
4640634 Cartridge, Holding Valve (May 1992 to S/N 29913) 1
2900770 Seal Kit - 4640634 Valve 1
4640996 Cartridge, Holding Valve (S/N 29913 to Present) 1
Consult Factory Seal Kit - 4640996 Valve 1
— — — — — — — — — —
0100038 Primer, Loctite A/R
0100011 Loctite #242 A/R
0100035 Loctite #222 A/R
— — — — — — — — — —
2901206 Seal Kit (Includes Items 12-18) 1
