JLG 110HXER ANSI Parts Manual - Manual (Page 266)

5-28 3120637
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
S
30 Setscrew Options: A/R
3951403 Setscrew 1/4"-20NC x 3/8" (Prior to January 1991) 2
3900171
Setscrew 1/2"-13NC x 1/2" (January 1991 to
Present)
1
31 2200221 Plug, Pipe 1/8" NPT 1
32 2200224 Plug, Pipe 3/8" NPT 2
33 2200222 Plug, Pipe 1/4" NPT 1
34 Not Used
35 Not Used
36 3340566 Pad, Wear 1
— — — — — — — — — —
0100020 Sealant, Pipe A/R
0100011 Loctite #242 A/R
0100035 Loctite #222 A/R
0100038 Primer, Locking A/R
— — — — — — — — — —
2901109
Seal Kit (Includes Items 13-20) (Prior to October
1992)
1
2901234
Seal Kit (Includes Items 13-20) (October 1992 to
Present)
1
FIGURE 5-13. TELESCOPE CYLINDER ASSEMBLIES (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
