SECTION 3 BOOM
FIGURE 3-6. BOOM WIPERS INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
BOOM WIPERS INSTALLATION
Ref.
0239257
Prior To May 1992
Ref.
A
0253303
May 1992 To Present
Ref.
2
1 to 6
Not Used
7
0540074
Brush, Wiper (Base Top)
1
8
Not Used
9
0540078
Brush, Wiper (Outer Mid Top)
1
10
0540075
Brush, Wiper (Base Side)
2
11
0540077
Brush, Wiper (Inner Mid Side)
2
12
0540079
Brush, Wiper (Outer Mid Side)
2
13
2660067
Holder (Base Top)
1
14
Not Used
15
2660071
Holder (Outer Mid Top)
1
16
2660068
Holder (Base Side)
2
17
2660070
Holder (Inner Mid Side)
2
18
2660072
Holder (Outer Mid Side)
2
19
3820001
Rivet
30
20
1670491
Cover
1
21
0641404
Bolt 1/4"-20NC x 1/2"
4
22
4761400
Lockwasher 1/4"
4
23
4711600
Flatwasher 3/8"
4
24 to 50
Not Used
51
Mount, Wiper (Base Top) Options:
1
3200286
Prior to May 1992
3200344
May 1992 to Present
52
Mount, Wiper (Inner Mid Top) Options:
A/R
3200288
Prior to May 1992
1
3200346
May 1992 to Present
2
53
Mount, Wiper (Outer Mid Top) Options:
1
3200290
Prior to May 1992
3200348
May 1992 to Present
54
Mount, Wiper (Base Side) Options:
2
3200287
Prior to May 1992
3200345
May 1992 to Present
55
Mount, Wiper (Inner Mid Side) Options:
2
3200289
Prior to May 1992
3200347
May 1992 to Present
56
Mount, Wiper (Outer Mid Side) Options:
2
3200291
Prior to May 1992
3200349
May 1992 to Present
57
Brush, Wiper (Inner Mid Top) Options:
A/R
0540076
Prior to May 1992
1
0540089
May 1992 to Present
2
58
Holder (1 Piece) (Inner Mid Top) Options:
A/R
2660069
Prior to May 1992
1
2660085
May 1992 to Present
2
