FIGURE 6-4. HYDRAULIC DIAGRAM - DRIVE
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
2791423
HYDRAULIC DIAGRAM - DRIVE
Ref.
6
1
2751466
Hose
1
2
2220415
Fitting, Straight
2
3
2220800
Fitting, Straight
5
4
Not Used
5
2220451
Fitting, Straight
2
6
2220385
Fitting, Tee
2
7
2220618
Fitting, Reducer
2
8
2750889
Hose
2
9
2220466
Fitting, 90°
2
10
2220414
Fitting, Straight
2
11
4640013
Valve, Shuttle
1
12
2220261
Fitting, Straight
1
13
4640197
Valve, Check
1
14
2220673
Fitting, 90°
1
15
2220417
Fitting, Straight
1
16
Not Used
17
Not Used
18
2751010
Hose
1
19
2220602
Fitting, Tee
1
20
0100020
Sealant, Pipe
A/R
21
2750979
Hose
1
22
2750759
Hose
2
23
2220362
Fitting, Tee
1
24
2220374
Fitting, Straight
2
25
2750894
Hose
4
26
2220504
Fitting, Tee
2
27
Not Used
28
2220585
Fitting, 90°
1
29
2220466
Fitting, 90°
2
30
Not Used
31
Not Used
32
Not Used
33
2751013
Hose
1
34
2220465
Fitting, 90°
2
35
2751339
Hose
2
36
2220435
Fitting, Straight
2
37
Not Used
38
Not Used
39
2750759
Hose
1
40
Not Used
41
Not Used
42
2751409
Hose
1
43
2220375
Fitting, Straight
2
44
2751489
Hose
3
45
2751337
Hose
2
46
2220568
Fitting, 45°
2
47
2220500
Fitting, 45°
1
