SECTION 5 CYLINDER
FIGURE 5-5. PLATFORM LEVEL CYLINDER ASSEMBLY (100HX+10 & 110HXER BUILT PRIOR TO
MAY 1992)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLY OPTIONS: Ref.
1681791 Prior To February 1991 Ref. F
1682459 February 1991 To May 1992 Ref. 2
1 Barrel Assembly Options: 1
1681796 Prior To February 1991 1
1682460 February 1991 To May 1992 1
2 1681797 Rod Assembly 1
0961182 Bushing, Bronze 2
3 1681792 Head 1
4 1120305 Retainer 1
5 4563657 Spacer 1
6 3480124 Piston 1
7 Nut Options: 1
3300234 Nut (Prior to January 1991)
3300276 Nut, Hex (January 1991 to May 1992)
8 4640509 Valve, Cartridge - Holding 2
2900792 Seal Kit - 4640509 Valve (1 Per Cartridge) 2
9 Kit Seal, Wiper 1
10 Kit Seal, Rod 1
11 Kit Ring, Wear 1
12 Kit O-Ring 1
13 Kit Ring, Wear 1
14 Kit T-Seal 1
15 Kit O-Ring 1
16 Setscrew Options: A/R
3951403 Setscrew 1/4"-20NC x 3/8" 2
3900170 Setscrew 3/8"-16NC x 3/8" 1
17 Plug, Pipe 1/4” Options: 2
2200213 Prior to S/N 39439
2200233 S/N 39439 to Present
18 Plug, Pipe 1/8” Options: 2
2200201 Prior to S/N 39439
2200221 S/N 39439 to Present
19 0100020 Sealant, Thread A/R
20 2160002 Fitting, Grease 3
21 0100011 Loctite #242 A/R
22 0100038 Primer, Locking A/R
23 0100035 Loctite #222 A/R
— — — — — — — — — —
2900394 Seal Kit - Cylinder (Includes Items 9-15) 1
