2-98 3120637
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
182 4761000 Lockwasher #10 4
183 3311001 Nut #10-24NC 4
184 0080091 Adapter, Choke 1
185 2720160 Hose 1/2" 28in/71cm
186 1060045 Cable, Battery (Engine to Ground) 1
187 0701010 Bolt, Metric M10 x 1.5 x 20mm 2
188 0701013 Bolt, Metric M10 x 1.5 x 28mm 2
189 4832000 Lockwasher, Metric M10 4
190 4564281 Tube, Dipstick 1
191 Dipstick Options: 1
2420109 Prior to S/N 39075
2420189 S/N 39075 to Present
192 4566628 Exhaust Weldment 1
193 0902098 Bracket, Exhaust 1
194 4751500 Flatwasher 5/16" Narrow 3
195 4562516 Tube, Hose 1 in./2.5cm
196 1320032 Clamp 1
197 3311505 Locknut 5/16"-18NC 2
198 4771600 Starwasher 3/8" 2
199 0641610 Bolt 3/8"-16NC x 1 1/4" 1
200 4921766 Harness, Engine (See Section 7 for Breakdown) 1
201 0100030 Adhesive, Sealant A/R
202 4920967 Harness, Ground 1
203 3538387 Panel, Electrical 1
204 1703162 Decal 1
2000126 ENGINE COMPONENTS Ref.
301 7012680 Alternator 1
7019921 Belt, Alternator 1
7019929 Pulley, Idler (Tensioner Assembly) 1
302 7016600 Fuel Pump - Electric (Facet) 1
7016601 Filter, Fuel (Used with Facet Pump) 1
303 7012682 Harness, Engine 1
304 7012681 Module, Ignition 1
7019930 Coil, Ignition 1
7019932 Plug, Spark 4
7019931 Spark Plug Wire Set 1
Use 7012682 Harness, Ignition (was p/n 7019922) 1
305 7012679 Starter (Far Side - Not Shown) 1
306 Use 7021869 Filter, Oil (was p/n 7014501) 1
307 7012690 Carburetor 1
7019933 Carburetor Repair Kit 1
7023471 Carburetor Float Assembly 1
7000646 Gasket, Carburetor (Base) 1
7025145 Gasket, Carburetor (Top) 1
7016605 Choke, Automatic 1
FIGURE 2-27. FORD LRG-423 ENGINE INSTALLATION - (MARCH 1995 TO S/N 35742)
(CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
