SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
39 4770800 Starwasher #8 2
40 3310801 Nut #8-32NC 2
41 1700821 Decal - Wire Identification 1
42 4843384 Air Intake Weldment 1
43 4640742 Valve, Drain 1
44 2720042 Hose, Heater 6 in./15cm
45 4921140 Engine Harness (Not Shown) 1
46 2420073 Sender, Oil Pressure 1
47 Not Used
48 0641812 Bolt 1/2”-13NC x 1 1/2” 2
49 4761800 Lockwasher 1/2” 2
50 0701217 Bolt, Metric 12mm x 45mm (S/N 36614 to Present) 4
51 1320222 Clamp (S/N 38344 to Present)
52 to 59 Not Used
60 Engine, Deutz F4L912 Options: 1
2000083 Standard F4L912 Engine
2000115 Clean Burn F4L912 Engine
DEUTZ ENGINE INSTALLATIONS Ref.
0253358 Standard Engine Installation Ref. 5
0253360 Clean Burn Engine Installation Ref. 4
0255612 EXHAUST INSTALLATION Ref. 2
77 0641408 Bolt 1/4”-20NC x 1” 4
78 4844238 Tube 1
79 1670627 Cover, Base Plate 1
80 1340020 Air Cleaner Assembly 1
7004214 Filter 1
81 0340002 Band, Mounting 2
82 0080046 Elbow 1
83 0080039 Elbow A/R
84 4565655 Tube 1
85 2720224 Hose 1
86 1320058 Clamp A/R
87 4300031 Stud (Welded on Part) 8
88 4761400 Lockwasher 1/4” 12
89 3311401 Nut 1/4”-20NC 12
90 0400020 Battery 1
91 0236768 Rod, Tie-Down 4
92 0361027 Strap, Tie-Down 1
93 3980006 Seat, Masonite 1
94 0400003 Battery 1
95 0400002 Tie-Down, Battery 1
96 3980003 Seat, Masonite 1
97 4751400 Flatwasher 1/4” A/R
98 3300029 Wingnut 3/8”-16NC 4
99 1060031 Cable, Battery (- Batt to Ground) 1
100 1060109 Cable, Battery (+ Batt to Start Solenoid) 1
101 1060149 Cable, Battery (Start Solenoid to Aux Relay) 1
FIGURE 2-21. DEUTZ ENGINE INSTALLATION WITH NOISE REDUCTION (BUILT OCTOBER 1992
TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
