SECTION 5 CYLINDER
FIGURE 5-3. PLATFORM LEVEL CYLINDER ASSEMBLY (100HX & 110HX BUILT PRIOR TO MAY
1992)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1681973 PLATFORM LEVEL CYLINDER ASSEMBLY Ref. E
1 1681976 Barrel Assembly 1
2 4640509 Valve, Cartridge 2
2900792 Seal Kit - 4640509 Valve (1 Per Cartridge) 2
3 2200202 Plug, Pipe 2
0100020 Sealant, Pipe A/R
4 2200201 Plug, Pipe 6
0100020 Sealant, Pipe A/R
5 Nut Options: 1
3300257 Nut, Standard Production (Without Setscrew)
3300301 Nut, Hex Style Replacement (Requires Setscrew)
3900170 Setscrew 3/8"-16NC x 3/8" (Not Shown) 1
0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
6 3480120 Piston 1
7 Kit Ring, Wear 1
8 Kit Seal, Piston 2
9 Kit O-Ring 1
10 4564057 Spacer 1
11 1680892 Head 1
12 Kit Ring, Wear 1
13 Kit Ring, Back-up 2
Kit O-Ring 1
14 Kit Seal, Rod 1
15 Kit Seal, Wiper 1
16 1120179 Retainer 1
0100035 Loctite #222 A/R
17 1681974 Rod Assembly 1
18 0960097 Bushing 1
19 2160002 Fitting, Grease 2
— — — — — — — — — —
2900381
Seal Kit - 1681973 Cylinder (Includes Items 7-9 &
12-15)
1
