SECTION 3 BOOM
221 Roller Options: 2
3860046 4620038 & 4620044 Turntable Machines
3860050 4620078 Turntable Machines
222 Clamp, U-Bolt Options: 2
1320072 4620038 & 4620044 Turntable Machines
1320155 4620078 Turntable Machines
223 Carrier Tube Weldment (Right Side) Options: 1
1180189 4620038 & 4620044 Turntable Machines
1180254 4620078 Turntable Machines
224 Power Track (Right Side) Options: 1
224A Power Track 4620038 & 4620044 Turntable
Machines:
Use 1001119693 Machines without Chip Covers & 4620038 &
4620044 Turntable (was p/n 1180106 - Gemco
is Original Equipment/Gortrac is Service
Replacement)
1180177 Machines with Chip Covers & 4620038 &
4620044 Turntable
224B Gemco Power Track Replacement Parts
(4620038 & 4620044 Turntable Machines):
7006178 Repair Section - 1 Foot without Chip Covers A/R
7006186 Repair Section - 1 Footwith Chip Covers A/R
Use 7006143 Bracket, Mounting (Includes 1 left, 1 right
mounting brackets & 2 spacers) (was p/n
7006179) 4
Use 7006138 Pin Assembly (Includes 1 link pin, 1
retaining ring & 4 washers of various
thicknesses) (was p/n 7006180) A/R
224C Gortrac Power Track Replacement Parts
(4620038 & 4620044 Turntable Machines):
70003149 Repair Section (Includes 1 set of attaching
hardware) (1001119693 Power Track Only) A/R
70003150 Mounting Bracket Kit (Includes 4 mtg feet &
hardware to attach to track) (1001119693
Power Track Only) A/R
224D Power Track 4620078 Turntable Machines :
1180236 Machines without Chip Covers - 4620078
Turntable
1180258 Machines with Chip Covers - 4620078 Turntable
Use 1001119697 Machines with Inverted Powertrack - 4620078
Turntable (was p/n 1180289 - Gemco is Original
Equipment/Gortrac is Service Replacement)
224E Gemco Power Track Replacement Parts
(4620078 Turntable Machines):
7006153 Repair Section - 1 Foot without Chip Covers A/R
7006145 Repair Section - 1 Foot with Chip Covers A/R
7006503 Repair Section - 1 Foot with Inverted Power
Track A/R
Use 7006143 Bracket, Mounting (Includes 1 left, 1 right
mounting brackets & 2 spacers) (was p/n
7006179) 4
FIGURE 3-1. BOOM ASSEMBLY COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
